Etienne_SamsonEtienne_Samson Beta Tester Beetle, Wrist Camera URCap 1.3.0, Vacuum Beta tester Posts: 419 Handy
edited October 2016 in Robotiq Products
This how-to is intended for Robotiq 2-Finger (85 or 140) 3.X install on any UR using controller CB2 / CB3

What you need :

  • Robotiq UR kit for 2-Finger (85 or 140 mm) (includes all cables and hardware)
  • UR 3, 5 or 10 robot with controller CB2 or CB3
  • Metric Allen key set (4 mm)
  • 2 mm slotted screwdriver

How to do it :

Mechanical installation :

  • Insert the provided 6 mm dowel pin into the UR wrist
  • Mount the 2-Finger Gripper coupling on the UR wrist, fix with the provided M6 x 10 mm screws
  • Mount the 2-Finger Gripper on it's coupling, first align the Gripper to the coupling dowel pin, then fix with the provided M5 x 35 mm screws

Electrical installation :

  • Connect the Gripper pigtail cable to the provided device cable
  • Pass your cable along the robot arm, make sure you have enough cable forgiveness to allow the UR to move freely in all directions. Attach with tie-wrap (or any cable holding system, may look better then tie-wraps...)
  • Wire the RS-485 to USB converter and wire the power to the UR controller according to this schematic :

Software setup :

  • Get the driver package for Robotiq Gripper at support.robotiq.com (look into each of the product section)
  • Unzip the package on a USB stick, plug into the UR, install is automatic
See my other post on how to use the Gripper with the provided template on UR.

Here is video showing the installation with a CB2 :

Etienne Samson
Technical Support Director
+1 418-380-2788 ext. 207
[email protected]
